Description
Why use a Lithium Battery?
Lithium LifePo4 batteries are the ideal replacement for traditional lead acid batteries. They last longer and recharge faster, saving time, saving money and reducing risk throughout their lifetime.
Safety:
Lithium LifePo4 battery chemistry is stable and safe. It is fitted with a Battery Management System (BMS) that actively monitors charge and discharge cycles to protect the cells against overcurrent, overvoltage and thermal runaway.
Installation:
LifePo4 batteries are lighter and more compact, making installation easier.
Performance:
Unlike traditional lead acid batteries, LifePo4 batteries charge faster with better efficiency and more lifecycles. A longer lifespan means having to replace your batteries less often.
| PERFORMANCE SPECIFICATIONS | |
|
Model |
Rack Mount |
|
Total Capacity |
5.12kWh |
|
Nominal Voltage |
51.2V/DC |
|
Maximum Charge Voltage |
58.4V/DC |
|
Discharge Cut-off Voltage |
40V/DC |
|
Max. Continuous Charge Current |
50A |
|
Max. Continuous Discharge Current |
100A |
|
Operating Temperature |
Charging: 0~45°C Discharging: -20~60°C Storage: 0~45°C |
|
Cycles |
3000 Cycles @100% D.O.D, remaining 80% Capacity |
|
Round Trip Efficiency |
95% |
|
Recommended Depth of Discharge |
≤85% |
|
Maximum Depth of Discharge |
100% |
|
Cooling Method |
Natural |
|
Shell Material |
Metal |
|
Parallel Connection |
Up to 5 sets |
|
Monitoring Data |
Over-Charge, Over-Discharge, Over-Current and Short Circuit |
|
Design Lifespan |
15 – 20 Years |
|
Warranty |
5 Years |
